Louvers

LOUVERS

Application

Outdoor installation to take the air from the exterior or to expel the used air in Air-conditioning, Ventilating and Heating systems. Louvers are designed to prevent rain penetration.

Mounting

Overlapped in the wall by means of visible screws or side frames to fix in place.

Implementation

Frame with flat frontal face of 30mm and inner fixed blades inclined at 45°, from 27 to 32mm pitch according to sizes. Diamond mesh of 13mm x 13mm fixed on back side of the louver to avoid the entrance of foreign bodies into the installation. Provides a neat external appearance to the building. Available in standard or non-standard sizes.

STANDARD FINISHES
Available in Natural Aluminium, Anodized or Powder coated in standard RAL white colours.
