Stripline Diffusers

STRIPLINE DIFFUSERS

Application

Air supply or air return between 2.6 mtrs and 4.0 mtrs high in Air-conditioning, Ventilating and Heating systems.

Mounting

Overlapped in false ceiling by means of hidden fixing systems or by means of visible screws on the flanges. .

Implementation

Extruded aluminium construction. Ideally designed for ceiling installation. High diffusion rates leading to rapid temperature and velocity equalization. Effcient and draft free horizontal air flow pattern. Frame with flat frontal face of 30 mm and 45 degree angled center blades assembly made of aluminium. Available in one way or two way , all standard and non-standard sizes.

STANDARD FINISHES:

Available in Natural Aluminium, Anodized or Powder coated in standard RAL white colours.
