Non-Vision or Door Transfer Grilles

NON-VISION OR DOOR TRANSFER GRILLES

Application

Air supply or air return in Air-conditioning, Ventilating and Heating systems

Mounting

Fixing on the doors to transfer the air from one cabin to another cabin and also in the toilet doors fixing by means of visible screws.

Implementation

Non Vision Grilles constructed in high grade aluminium extrusions with telescopic frames and V Shaped blades for air transfer. Frame with flat frontal face of 30 mm and V type sight proof fixed louvers. Available in standard or non - standard sizes, to be fixed with the door thickness from 19mm to 38mm .

Standard Finishes

Natural Aluminium, Anodized or Powder coated in standard RAL white colours.
